MW Mean Well Original HVG-65-48B 48V 1.3A 65W Single Output LED Switching Power Supply

Description

Features
Constant voltage+constant current modes
180~528VAC wide input range
Built-in active PFC function
High efficiency up to 90%
Protections: Short circuit / Over current / Over voltage /Over temperature
Cooling by free air convection
OCP point adjustable through output cable or internal potentiometer
IP67/IP65 design for indoor or outdoor installations
Class 2 power unit
Three in one dimming funtion(0~100Vdc or 10V PWM signal or resistance)
Type HL LED Driver for use in Class I, Division 2 hazardous location luminaires (HVG-100/150)
Suitable for dry, damp, and wet location
Suitable for LED lighting and street lighting applications
Compliance to worldwide safety regulations for lighting
A-Type: IP65 rated. Output voltage and constant current level can be adjusted through internal potentiometer
B-Type: IP67 rated and built-in 3 in 1 dimming function(0~10VDC, PWM signal, or resistance)
D-Type (option): IP67 rated. Timer dimming function,contact MEAN WELL for details
5 years warranty
