MW Mean Well ELG-75-C1400A 54V 1400mA 75.6W Single Output Switching LED Power Supply with PFC

Description

• Constant current output with high output voltage>60VDC
• Meet 6KV surge immunity level (IEC61000-4-5)
• No load power consumption <0.5W
• Type HL LED Driver for use in Class I, Division 2 hazardous location luminaires
• 5 years warranty

Features
Constant current output with high output voltage>60VDC (except ELG-75-C1400)
2180~295VAC input only
Built-in active PFC function
High efficiency up to 93%
Protections: Short circuit / Over voltage / Over temperature
Cooling by free air convection
Output current adjustable through output cable or internal potentiometer
IP67 / IP65 design for indoor or outdoor installations
Suitable for dry / damp / wet locations
Suitable for LED lighting and street lighting applications
Meet 6KV surge immunity level (IEC61000-4-5)
No load power consumption <0.5W
Type HL LED Driver for use in Class I, Division 2 hazardous location luminaires
Multiple models for choice:
Blank-Type: IP67. Cable for I/O connection
A-Type: IP65 rated. Constant current level can be adjusted
through internal potentiometer
B-Type: IP67 rated and built-in 3 in 1 dimming function(0~10VDC, PWM signal, or resistance)
D-Type (option): IP67 rated. Smart Timing Dimming function
5 years warranty
