MEAN WELL MW HLG-80H-36 36V 2.3A 82.8W Single Output Switching LED Driver with PFC

Description

• Universal AC input (up to 305VAC) / Full range
• High efficiency up to 93.5%
• Built-in active PFC function
• Suitable for dry, damp, and wet location
• 7 years warranty

FeaturesUniversal AC input (up to 305VAC) / Full rangeProtections: Short circuit / Over current / Over voltag e / Over temperatureBuilt-in active PFC functionHigh efficiency up to 93.5%IP67 / IP65 design for indoor or outdoor installationsOutput current adjustable through output cable or internal potentiometerCooling by free air convectionSuitable for dry, damp, and wet locationSuitable for LED lighting and street lighting applicationsMeet 4kV surge immunity level (IEC61000-4-5)Class 2 power unit / Pass LPS (except for HLG-120H)Multiple models for choice:A-Type: IP65 rated. Output voltage and constant current level can be adjusted through internal potentiometerB-Type: IP67 rated and built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance)Blank-Type: IP67 rated. Cable for I/O connectionBL-Type(option): for HLG-80H B-Type only, "UL8750 listed" safety & IP66 approved, contact MEAN WELL for detailsD-Type(option): IP67 rated. Timer dimming function, contact MEAN WELL for details (safety pending for 100W/120W)Optional CCC models available (HLG-80H/100H/120H-A/B/Blank type)7 years warranty
