Mean Well DDR-480B-12 480W DIN Rail Type DC-DC Converter 12V 33.4A Fully Modular Power Supply

Description

• Wide Operating Temperature Range: Functions reliably in extreme conditions from -40C to +80C for demanding industrial environments
• Peak Load Capability: Delivers 150% peak load capability to handle temporary power surges and startup requirements
• Current Sharing Function: Supports current sharing up to 1920W with 3+1 configuration for expanded power capacity
• DIN Rail Installation: Can be easily installed on standard DIN rail TS-35/7.5 or 15 for convenient mounting
• Reinforced Isolation: Features 4KVdc input/output isolation with reinforced isolation for enhanced safety and protection
• Ultra Slim Design: Compact width of 85.5mm allows space-saving installation in tight cabinet configurations
• Fanless Operation: Operates without a fan for silent performance and maintenance-free reliability
• Multiple Voltage Options: Available in 12V 33.4A, 24V 20A, and 48V 10A output configurations to suit various applications

NEW, MEAN WELL Power Supply. DDR-480 series is a 480W DlN Rail type DC-DC converter with main features including DlN rail-type easy installation, ultra slim width (85.5mm), 2:1 wide input voltage, fanless design, -40~+80 wide operating temperature, 4KVdc l/O isolation, 150% peak load, current sharing,DC OK, adjustable output voltage and full protective functions. This series of models has various input options: 16.8~33.6V / 33.6~67.2V /67.2~154V and multiple output options: 12V / 24V / 48V and can be used for industrial & railway control, security control, communication system and other fields. Suitable applications include to DC buck/boost regulator, increasing system insulation level and voltage drop compensation along cable...etc.
