20948 MCU 20948 Sensor Module Low Power 9 Axis MEMS Motion Tracking Device Sensor Module

Description

• Comprehensive motion detection capability: Built-in 3-axis gyroscope, 3-axis accelerometer and 3-axis magnetic field sensor accurately detect all movement changes, including rotation, acceleration and direction.
• High accuracy, programmability: the gyroscope has programmable full-range speeds (250 DPS, 500 DPS, 1000 DPS and 2000 DPS) and the accelerometer has selectable 2 g, 4 g, 8 g and 16 g measuring ranges. as well a wide on magnetic magnetic Field measurements up to 4900 T ensure accuracy and flexibility in a variety of application environments.
• INTEGRATED (DMP): Provides advanced computing capabilities that reduce the load on the main processor for more efficient data analysis and real-time motion detection.
• ADVANCED MEMS PACKAGE TECHNOLOGY: The use of hermetic sealing and connection technology at the wafer level can effectively improve the stability and durability of the sensor.
• INTEGRATED INTEGRATED TEMPERATURE SENSOR: Provides ambient temperature data and helps calibrate and compensate motion data, improving overall system reliability.

Technical data:
Item Type:MEMS Motion Tracking Sensor Module
Material: PCB
3-Axis Gyroscope: Programmable +250DPS, +500DPS, +250DPS and +2000DPS
3-axis accelerometer: programmable 2g, 4g, 8g and 16g.
3-axis magnetic field: wide range up to 4900 t.
Features: Built-in digital motion processor (DMP). Additional I2C interface for external sensors. On-chip 16-bit ADC and programmable filters. 7MHz SPI or 400kHz Fast Mode I Square C. Temperature sensor with digital output. MEMS structure hermetically sealed and connected at wafer level. Support for .

Application:
Install and use.

Package list:
1 x MEMS motion tracking sensor module.
1 x pen
