Beuiouer VL53L1X Ranging Flight Time Sensor Module 3V-5V Distance 400cm Measurement Extension Board Module for, Black

Description

• Typical full field-of-view (FoV): 27 degree;Programmable region-of-interest (ROI) size on the receiving array, allowing the sensor FoV to be reduced;Programmable ROI position on the receiving array, providing multizone operation control from the host
• Fully integrated miniature module;Emitter: 940 nm (Class1);SPAD (single photon diode) receiving array with integrated lens;Low-power microcontroller running advanced digital firmware
• Pin-to-pin compatible with the FlightSense ranging sensor;Fast and accurate long distance ranging;Up to 400 cm distance measurement;Up to 50 Hz ranging frequency
• Easy integration;Single reflowable component;Can be hidden behind many cover window materials
• Software driver and code examples for turnkey ranging;Single power supply (2v8);I2;C interface (up to 400 kHz);Shutdown and interrupt pin

Beuiouer Description: The VL53L1X is a state-of-the-art, Time-of-Flight (ToF), ranging sensor, enhancing the FlightSense product family. It is the fastest miniature ToF sensor on the market with accurate ranging up to 4 m and fast ranging frequency up to 50 Hz Unlike conventional IR sensors, the VL53L1X uses 's latest generation ToF technology which allows absolute distance measurement whatever the target color and reflectance. It is also possible to program the size of the ROI on the receiving array, allowing the sensor FoV to be reduced. colour: black Material: metal size: 25x10.7x3.2mm Package Contents: 1*VL53L1X Sensor Module 1*Optical cover Only the above package content, other products are not included. Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
